DWTB-C labeling machine
DWTB-C is economical, self contained, easy to operate, equipped with auto teach programming touch screen. Built in microchip storing different job setting makes fast and easy changeover. This automatic labeling system is ideal for slim cylindrical container with diameter from10mm-25mm such as ampoule
DWTB-C is economical, self contained, easy to operate, equipped with auto teach programming touch screen. Built in microchip storing different job setting makes fast and easy changeover. This automatic labeling system is ideal for slim cylindrical container with diameter from10mm-25mm such as ampoule.
- Key Features:
Labeling speed up to 250 CPM
Touch Screen Control System with Job Memory
Simple Straight Forward Operator controls
Full-set protecting device keep operation steady and reliable
On-Screen trouble shooting & Help Menu
Stainless Frame
Open Frame design, easy to adjust and change the label
Variable Speed with stepless motor
Label Count Down (for precise run of set number of labels) to Auto Shut Off
Stamping Coding Device attached
- Specifications:
Labeling Speed: 100-250 bottles/minutes (according to the specification, shape of bottle and length of label)
Bottles size: ø10-25 mm, height (can be customized based on the requirements)
Dimensions: 1600mm x 600mm x 1250mm (Length x Width x Height)
Weight: 185KG
Electrical Requirements:
— Power: 260W, Voltage: 220V, Frequency: 50-60HZ (Optional)
Working direction: Left-Right
- Industry Type(s)
Cosmetic/personal care
Household chemical
Food & beverage
Nutraceuticals
Pharmaceuticals
