Fume Hood
It is widely used in scientific research, biological & chemical experiment, electron, precision apparatus, instrument and so on.
Characteristics:
It is widely used in scientific research, biological & chemical experiment, electron, precision apparatus, instrument and so on.
To control exhausting the organic solvent and gas with poisonous, deleterious, flammable, to protect operator.
Parameter:
| Parameter/Model | TGH-1200 | TGH-1500 | TGH-1800 | ||
| Air displacement | 1200m3/h | 1500m3/h | 2000m3/h | ||
| Air tightness | 500Pa leakage rate≤10%(in 30min) | ||||
| Equiblast air volume | ≥0.4m/s | ||||
| Noisiness | ≤62dB(A) | ||||
| Vibration half peak value | ≤4μm | ||||
| Illumination | ≥300Lx | ||||
| Power supply | AC220V 50HZ | ||||
| Rated power consumption | 0.4kw | 0.6kw | 0.8kw | ||
| Weight | 150kg | 200kg | 250kg | ||
| Dimension of working area (W1xD1xH1) | 1000x650x800 | 1300x650x800 | 1600x650x800 | ||
| Overall dimension(W1xD1xH1) | 1200x800x2350 | 1500x800x2350 | 1800x800x2350 | ||
| Fluorescent lamp | 30Wx2 | 40Wx2 | 40Wx3 | ||
Related Products
-
Clean Room
What is Clean Room?
A Clean Room is an environment, typically used in manufacturing or scientific research that has a low level of environmental pollutants such as dust, airborne microbes, aerosol particles and chemical vapors. More accurately, a cleanroom has a controlled level of contamination that is specified by the number of particles per cubic meter at a specified particle size. To give perspective, the ambient air outside in a typical urban environment contains 35,000,000 particles per cubic meter in the size range 0.5µm and larger in diameter, corresponding to an ISO9 cleanroom, while an ISO1 cleanroom allows no particles in that size range and only 12 particles per cubic meter of 0.3µm and smaller.
What we can do?
We kindly needs following information to design your clean room
- Panel style:
- Metal-face polyurethane core board,
- Metal-face Rockwool core board (widely used),
- Metal-face polystyrene core board (without fire proof),
- Metal-Face Honeycomb Core Board,
- Metal-Face Plastered Core Board (widely used for ceiling),
- Metal-face glass-magnesium core board.
- Panel thickness: 50 mm, 70 mm and 100 mm.
- Panel Height & Color: according to customer request.
- Doors and windows manufacturing.
- Layout drawings.
-
Galvanized Steel Wall
The Galvanized Steel (GS) partition wall is a structure with a thickness of
50 mm, made of 2 x 0.6 mm thick external Galvanized Steel panels, 2 x 5 mm flameproof board and internal insulation, which vary according to the project requirements.
Each panel made is completely sealed on all 4 sides, using special profiles, designed to create the structure and complete closure of the internal insulation.
Ultra-med supplies different types of insulation: rock wool (RW), polystyrene (EPS), aluminum and paper honeycomb (HC), polyurethane (PUR).
In all cases, the densities of such insulations are extremely high, so as to guarantee superior mechanical stability of the wall itself.
-
Air Shower
This is a kind of local purifying equipment, fixed on the partition between clean room and unclean room. It is used for shower and removing dust when personnel or objects entering into clean area. Effectively reduce dust source from entering into clean area after used, and keep clean area in normal working state. Shower way: single-side shower, double-side shower, three-side shower, top shower
-
Roll-Up doors
The panel is flexible with no rigid elements, it is self-repairing as it automatically fits back onto the slide rails, and rolls up inside the box which houses the motor.
They are fast moving and flexible doors that provide easy and functional transportation of materials from one area to another within the clean room.
Sliding guides and structures in painted steel, fiberglass.
It is also possible to insert transparent bands, which allow visibility through the roller blind.
Sheet: reinforced polyester (PE-UHMW 1000)
Opening speed: up to 1.5 m/s
Application: ultra-med partition plasterboard or brick wall
Sheet colors: according to customer request.
